At Atlas, we set the standard for excellence in lantern roof design. If you’re looking for a completely symmetrical glass roof system, our square roof lanterns are a good option. They’re designed and manufactured to the same high standards as our contemporary and traditional ranges, built as a square rather than a rectangular piece. They’re also offered in five stock sizes or hundreds of bespoke, made-to-measure sizes, with the same fantastic range of styles and colours.
Key Specifications
- As standard, our glass keeps heat out, insulates, blocks 91% of harmful UV rays, reduces fading, and stays cleaner for longer with built-in self-cleaning technology
- Tested up to a uniformly distributed load of 3.5 KN/m2 for strong performance
- All double-glazed units incorporate toughened safety glass, manufactured to the highest British and European Standards, accredited to BS EN 1279 parts 2 & 3 and BS EN 12150
-
Industry-leading ridge and rafter U Values – double glazing rafter 1.5 W/m2K as standard and rafter U Value as low as 0.9 W/m2K with triple glazing
- Hundreds of bespoke made-to-measure options
- 38% slimmer internal hip than alternatives
- 60% slimmer internal ridge than alternatives
- Over 50% lower external bulk
- Stock lantern pitch of 25 degrees with variable alternatives available on request, with certain styles
- Thermal break prevents cold from getting to the inside of the rafter
- Roof proportionately correct with ridge and hips all 40mm
- Contemporary roof lanterns available in stock sizes ranging between 1000 x 1500 to 1500 x 3000
- Traditional roof lanterns available in stock sizes ranging from 1000 x 2000 to 2000 x 4000
- Square roof lanterns available in stock sizes between 1000 x 1000 to 2000 x 2000
- Please note, we offer bespoke sizes for all our roof lanterns, up to a maximum of 5m x 10m.
Available Configurations
The Atlas Roof Lantern offers a range of options to suit your specific requirements. From different sizes and finishes to various glazing options, you can create a roof lantern that perfectly complements a projects unique style and architecture.
- Stock RAL Colours
- Dual colour available at no extra cost when selecting two stock colours
- Available in contemporary, traditional, square or circular style
- Bespoke RAL and BS colours available
- All Glass types are self-cleaning
